Запчасти Komatsu PC700LC-8E0 ЦИЛИНДР РУКОЯТИ, ВНУТР. ЧАСТИ ЦИЛИНДР РУКОЯТИ

|$1

707-01-0CA70

Cylinder Assembly

1

707-13-20630

Cylinder

2

707-58-14630

Rod

3

707-76-12150

Bushing

4

07145-00120

Seal, Dust, (K09)

5

707-76-12520

Bushing

6

07145-00125

Seal, Dust, (K09)

7

707-71-61510

Plunger

8

707-71-32920

Collar

9

07000-15190

O-Ring, (K09)

10

707-35-92020

Ring, Back-Up, (K09)

11

707-71-70370

Plunger

12

04260-00952

Ball

13

707-71-91230

Cap

14

707-27-20590

Head, Cylinder

15

707-56-14740

Seal, Dust, (K09)

16

07179-14160

Ring, Snap

17

707-51-14080

Packing, Rod, (K09)

18

707-51-14650

Ring, Buffer, (K09)

19

707-52-91171

Bushing

20

07000-15190

O-Ring, (K09)

21

707-35-92020

Ring, Back-Up, (K09)

22

707-75-14110

Ring, Snap

23

01011-82705

Bolt

24

01643-32780

Washer

25

707-36-20450

Piston

26

707-44-20150

Ring, Piston, (K09)

27

707-39-20020

Ring, Wear, (K09)

28

707-44-20910

Ring

29

07000-B5130

O-Ring, (K09)

30

07001-05130

Ring, Back-Up, (K09)

31

01310-01232

Screw

32

707-86-00450

Tube

33

707-88-50880

Bracket

34

707-88-26610

Band

35

07372-21250

Bolt

36

01643-51232

Washer

37

07372-21060

Bolt

38

01643-51032

Washer

39

07000-13035

O-Ring, (K09)

40

07371-51260

Flange

41

707-88-33050

Cap

42

01010-81245

Bolt

43

01643-31232

Washer

44

07371-51470

Flange, Split

45

707-88-33060

Cap

46

01010-81455

Bolt

47

01643-31445

Washer

48

707-88-10150

Clamp

K09

707-99-76380

Service Kit, Arm Cylinder
