Запчасти Komatsu PC700LC-8E0 ОСНОВН. ПОРШЕНЬ НАСОС, ВНУТР. ЧАСТИ, NO. НАСОС (/9) ОСНОВН. ПОРШЕНЬ НАСОС

|$0

708-2L-90722

Pump Assembly

|$1

708-2L-01622

Pump Subassembly

|$2

708-2L-04940

Case Assembly,Rear

1

Case,Rear

2

Plug

3

07044-12412

Plug

4

07002-62434

O-Ring

5

708-2L-21711

Cap, End

6

708-2L-32260

Bearing

7

07000-B2135

O-Ring

8

6130-21-1910

Pin, Dowel

9

07000-B2015

O-Ring

10

07000-B1009

O-Ring

11

07000-B5165

O-Ring

12

07000-B3032

O-Ring

13

708-25-12530

Bolt

14

04530-11018

Bolt, Eye

15

708-25-13630

Ring

16

708-2L-22440

Shaft,Rear

17

708-2L-32150

Bearing

18

708-2E-05040

Washer Kit

18

Washer, T=3.1mm

18

Washer, T=3.0mm

18

Washer, T=2.9mm

18

Washer, T=2.8mm

19

708-25-12790

Ring, Snap

20

708-25-05021

Shim Kit

20

Shim, T=0.5mm

20

Shim, T=0.2mm

20

Shim, T=0.15mm

20

Shim, T=0.1mm

21

708-25-12950

Plate

22

706-74-40320

Bolt

23

01643-31032

Washer

24

01252-31016

Bolt

25

708-25-05130

Shim Kit

25

Shim, T=0.2mm

25

Shim, T=0.1mm
