Запчасти Komatsu PC700LC-8E0 УПРАВЛЯЮЩ. КЛАПАН (СОЕДИНИТЕЛЬН. ЧАСТИ) (/) H [ГИДРАВЛИКА]

1

207-62-56190

FLANGE

2

01010-81040

BOLT

3

01643-31032

WASHER

4

07000-13035

O-RING

5

21M-62-14330

ELBOW

6

21M-62-14340

ELBOW

7

02896-11009

O-RING

8

07002-12034

O-RING

9

206-06-61130

SWITCH, PRESSURE

10

203-973-5610

UNION

11

07002-12034

O-RING

|$12

21M-60-11510

VALVE ASSEMBLY

12

205-60-51410

SPRING

13

205-60-51420

SEAT

14

BODY

15

21M-60-11520

POPPET

16

04065-01410

RING

17

07002-12034

O-RING

18

21M-62-14411

TEE

19

07002-12034

O-RING

20

206-06-61130

SWITCH, PRESSURE

21

02896-11009

O-RING

22

07042-30108

PLUG

23

21M-62-21740

ELBOW

24

201-60-11390

O-RING

25

20Y-62-19560

O-RING

26

07002-12034

O-RING

27

02782-10315

ELBOW

28

07002-12034

O-RING

29

02896-11009

O-RING

30

21M-62-22510

ELBOW

31

07002-12434

O-RING

32

02896-11015

O-RING

33

02782-10315

ELBOW

34

07002-12034

O-RING

35

02896-11009

O-RING

36

21M-62-16670

ADAPTER

37

07002-11423

O-RING

38

20Y-62-21940

JOINT

39

07002-12034

O-RING
