Запчасти Komatsu PC700LC-8E0 ЦИЛИНДР СТРЕЛЫ(ЛЕВ.) T [РАБОЧЕЕ ОБОРУДОВАНИЕ]

|$1

ЎС707-01-XZP60

CYLINDER G.L.H(FINAL AOATURY)

|$2

707-01-0CA60

BOOM CYLINDER ASSEMBLY

1

721-13-18230

CYLINDER

2

707-58-12660

ROD, PISTON

3

707-76-11160

BUSHING

4

07145-00110

SEAL, DUST\((K08)\)

5

07020-00000

FITTING, GREASE

6

707-76-12530

BUSHING

7

07145-00125

SEAL, DUST\((K08)\)

8

707-71-32900

COLLAR

9

707-35-91840

RING, BACK-UP\((K08)\)

10

07000-15175

O-RING\((K08)\)

11

707-71-61330

PLUNGER

12

707-27-18930

HEAD, CYLINDER

13

707-56-12740

SEAL, DUST\((K08)\)

14

07179-13136

RING, SNAP

15

707-51-12030

PACKING, ROD\((K08)\)

16

707-51-12650

RING, BUFFER\((K08)\)

17

707-52-90981

BUSHING

18

07000-15175

O-RING\((K08)\)

19

707-35-91840

RING, BACK-UP\((K08)\)

20

07179-13126

RING, SNAP

21

01011-82400

BOLT

22

707-88-75410

WASHER

23

707-36-18520

PISTON

24

707-44-18250

RING, PISTON\((K08)\)

25

707-39-18510

RING, WEAR\((K08)\)

26

707-44-18920

RING

27

07000-B5110

O-RING\((K08)\)

28

07001-05110

RING, BACK-UP\((K08)\)

29

01310-01225

SCREW

30

707-86-13240

TUBE

31

707-86-00950

TUBE

|$34

21M-63-52180

TUBE

32

707-87-14700

PLUG

33

07002-63034

O-RING\((K08)\)

34

707-88-28240

BRACKET

35

707-88-26120

BAND

36

07372-21060

BOLT

37

01643-51032

WASHER
