Запчасти Komatsu PC700LC-8E0 ПРИВОД НАСОС (ВНУТР. ЧАСТИ, НАСОС ВЕНТИЛЯТОРА) (/7) H [ГИДРАВЛИКА]

|$1

708-1U-00202

PUMP ASSEMBLY

|$2

708-1U-00213

PUMP ASSEMBLY

|$3

708-1U-01218

PUMP SUBASSEMBLY

1

708-1U-13110

BLOCK, CYLINDER

2

708-1U-13211

PLATE, VALVE

3

720-68-19610

PIN

4

708-1W-43130

SEAT

5

708-1W-43140

SPRING

6

04065-04818

RING, SNAP

7

708-1W-43320

GUIDE, RETAINER

8

708-3T-13360

PIN

9

708-1U-13341

RETAINER, SHOE

10

708-1U-13310

PISTON SUBASSEMBLY

11

708-1W-44130

PISTON

12

708-3T-14120

SPRING

13

708-1U-14240

SCREW

14

07000-12011

O-RING

15

01643-31232

WASHER

16

01582-11210

NUT

|$1

708-1U-00202

PUMP ASSEMBLY

|$2

708-1U-00213

PUMP ASSEMBLY

|$3

708-1U-01218

PUMP SUBASSEMBLY

1

708-1U-13110

BLOCK, CYLINDER

2

708-1U-13211

PLATE, VALVE

3

720-68-19610

PIN

4

708-1W-43130

SEAT

5

708-1W-43140

SPRING

6

04065-04818

RING, SNAP

7

708-1W-43320

GUIDE, RETAINER

8

708-3T-13360

PIN

9

708-1U-13341

RETAINER, SHOE

10

708-1U-13310

PISTON SUBASSEMBLY

11

708-1W-44130

PISTON

12

708-3T-14120

SPRING

13

708-1U-14240

SCREW

14

07000-12011

O-RING

15

01643-31232

WASHER

16

01582-11210

NUT
