Запчасти Komatsu PC700LC-8E0 ПРИВОД НАСОС (ВНУТР. ЧАСТИ, НАСОС ВЕНТИЛЯТОРА) (/7) H [ГИДРАВЛИКА]

|$1

708-1U-00202

PUMP ASSEMBLY

|$2

708-1U-00213

PUMP ASSEMBLY

|$3

708-1U-01218

PUMP SUBASSEMBLY

|$4

708-1U-04143

CASE ASSEMBLY

1

CASE, PUMP

2

PLUG, STOCKING

3

708-8E-16160

PLUG

4

07002-11023

O-RING

5

07040-12412

PLUG

6

07002-12434

O-RING

7

706-73-42370

O-RING

8

07000-B1009

O-RING

9

04020-01024

PIN, DOWEL

10

01010-61470

BOLT

11

01643-31445

WASHER, FLAT

12

708-1U-11562

CAP, END

13

708-1W-42120

BEARING

14

708-1U-13461

BALL

15

708-1U-13450

CAM, ROCKER

16

04260-01270

BALL

17

708-1U-12120

SHAFT

18

708-1W-42110

BEARING

19

708-1U-42140

CASE, SEAL

20

708-1W-42130

SEAL, OIL

21

07000-B2060

O-RING

22

708-1W-05821

SPACER KIT

|$27

SPACER, T=1.8MM

|$28

SPACER, T=1.85MM

|$29

SPACER, T=1.9MM

|$30

SPACER, T=1.95MM

|$31

SPACER, T=2.0MM

|$32

SPACER, T=2.05MM

|$33

SPACER, T=2.1MM

|$34

SPACER, T=2.15MM

|$35

SPACER, T=2.2MM

23

04065-06825

RING, SNAP
