Запчасти Komatsu PC700LC-8E0 КОВШ (№-) КОВШ, .M, 7MM ШИР., WEAR ПЛАСТИНА, KMAX TOOTH, THRUST ADJUSTMENT, БОКОРЕЗЫ

Схема запчастей Komatsu PC700LC-8E0 - КОВШ (№-) КОВШ, .M, 7MM ШИР., WEAR ПЛАСТИНА, KMAX TOOTH, THRUST ADJUSTMENT, БОКОРЕЗЫ
14
5
19
3
7
6
4
1
19
2
13
20
15
16
8
10
8
9
11
21
17
22
9
18
12
26
25
24
18
23

Артикул

Название

Примечание

Количество

1

21M-939-2213

Bucket

2

21M-939-2261

Adapter,Welded

3

21M-939-2271

Adapter,Welded

4

21M-939-2220

Plate,Welded

5

21M-939-2230

Plate,Welded

6

21M-939-2240

Plate,Welded

7

21M-939-2252

Shroud,Welded

8

21M-939-2410

Plate,Welded

9

21M-939-2420

Plate,Welded

10

21M-939-2430

Plate,Welded

11

21M-939-2440

Plate,Welded

12

21M-939-2460

Plate,Welded

13

21M-939-2480

Plate,Welded

14

21M-939-2490

Plate,Welded

15

21M-939-2510

Plate,Welded

16

21M-939-2520

Plate,Welded

17

21M-939-2470

Plate,Welded

18

21M-939-2450

Plate,Welded

19

21M-939-2530

Plate,Welded

20

21M-939-2540

Plate,Welded

21

21M-939-2281

Tooth

22

21M-939-2291

Pin Assembly

23

209-70-54171

Cover

24

01010-82480

Bolt

25

01643-32460

Washer

26

209-72-54220

Bushing

Выбрано товаров: 26
