Запчасти Komatsu PC700LC-8E0 КОВШ (№-) КОВШ, .M, MM ШИР., WEAR ПЛАСТИНА, KMAX TOOTH, THRUST ADJUSTMENT, БОКОРЕЗЫ

Схема запчастей Komatsu PC700LC-8E0 - КОВШ (№-) КОВШ, .M, MM ШИР., WEAR ПЛАСТИНА, KMAX TOOTH, THRUST ADJUSTMENT, БОКОРЕЗЫ
2
19
1
4
6
7
3
19
5
14
13
20
15
16
23
28
18
24
25
26
27
12
18
9
22
17
21
11
9
8
10
8

Артикул

Название

Примечание

Количество

1

21M-939-2322

Bucket

2

21M-939-2261

Adapter,Welded

3

21M-939-2271

Adapter,Welded

4

21M-939-2330

Plate,Welded

5

21M-939-2230

Plate,Welded

6

21M-939-2240

Plate,Welded

7

21M-939-2252

Shroud,Welded

8

21M-939-2410

Plate,Welded

9

21M-939-2420

Plate,Welded

10

21M-939-2550

Plate,Welded

11

21M-939-2560

Plate,Welded

12

21M-939-2570

Plate,Welded

13

21M-939-2580

Plate,Welded

14

21M-939-2590

Plate,Welded

15

21M-939-2510

Plate,Welded

16

21M-939-2520

Plate,Welded

17

21M-939-2470

Plate,Welded

18

21M-939-2450

Plate,Welded

19

21M-939-2530

Plate,Welded

20

21M-939-2540

Plate,Welded

21

21M-939-2281

Tooth

22

21M-939-2291

Pin Assembly

23

209-70-54171

Cover

24

01010-82480

Bolt

25

01643-32460

Washer

26

209-70-54160

Bushing

27

209-72-54220

Bushing

28

209-70-00082

Shim Assembly

28

Shim, T=1.0mm

28

Shim, T=0.5mm

Выбрано товаров: 30
