Запчасти Komatsu PC700LC-8E0 УПРАВЛЯЮЩ. КЛАПАН, СОЕДИНИТЕЛЬН. ЧАСТИ (/) (№-) УПРАВЛЯЮЩ. КЛАПАН

1

207-62-56190

Flange

2

01010-81040

Bolt

3

01643-31032

Washer

4

07000-13035

O-ring

5

21M-62-14330

Elbow

6

21M-62-14340

Elbow

7

02896-11009

O-ring

8

07002-12034

O-ring

9

206-06-61130

Switch, Pressure

10

203-973-5610

Union

11

07002-12034

O-ring

11

21M-60-11510

Valve Assembly

12

205-60-51410

Spring

13

205-60-51420

Seat

14

Body

15

21M-60-11520

Poppet

16

04065-01410

Ring

17

07002-12034

O-ring

18

21M-62-14411

Tee

19

07002-12034

O-ring

20

206-06-61130

Switch, Pressure

21

02896-11009

O-ring

22

07042-30108

Plug

23

21M-62-21740

Elbow

24

201-60-11390

O-ring

25

20Y-62-19560

O-ring

26

07002-12034

O-ring

27

02782-10315

Elbow

28

07002-12034

O-ring

29

02896-11009

O-ring

30

21M-62-22510

Elbow

31

07002-12434

O-ring

32

02896-11015

O-ring

33

02782-10315

Elbow

34

07002-12034

O-ring

35

02896-11009

O-ring

36

21M-62-16670

Adapter

37

07002-11423

O-ring

38

20Y-62-21940

Joint

39

07002-12034

O-ring

40

8296-62-2160

Elbow

41

07002-11423

O-ring

42

02896-11009

O-ring

43

02782-10316

Elbow

44

07002-12034

O-ring

45

02896-11009

O-ring
