Запчасти Komatsu PC70-8 МОТОР ПОВОРОТА (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

708-7S-00151

MOTOR ASS'Y

|$3

708-7S-01281

MOTOR SUB ASS'Y

1

708-7S-13611

PLATE,SWASH

2

708-7S-21511

HOUSING

3

706-73-71450

PLUG

4

07002-61423

O-RING

5

709-25-11650

VALVE,CHECK

6

700-80-63230

SPRING

7

708-7S-21610

PLUG

8

07002-62434

O-RING

9

07000-B2145

O-RING

10

720-68-19610

PIN

11

01252-61245

BOLT

12

708-7S-22110

SHAFT

13

708-7S-22140

BEARING

14

708-7S-22150

BEARING

15

708-7T-12330

SEAL,OIL

16

708-7S-22310

COVER

17

07000-B2055

O-RING

18

04065-06020

RING,SNAP

19

708-7S-23111

BLOCK,CYLINDER

20

708-7S-23210

PLATE,VALVE

21

720-68-19610

PIN

22

708-2L-23360

PIN

23

708-7S-13530

SPACER

24

708-7S-23510

SPRING

25

04065-03212

RING,SNAP

26

708-1S-13350

GUIDE,RETAINER

27

708-1S-13340

RETAINER,SHOE

28

708-7S-23310

PISTON SUB ASS'Y

29

708-7S-23410

PLATE,THRUST

30

708-7S-25130

PLATE

31

708-7S-25120

DISC

32

708-7S-25140

PISTON,BRAKE

33

07000-B2130

O-RING

34

07000-B2120

O-RING

35

708-7S-25150

SPRING
