Запчасти Komatsu PC70-8 МАРКИРОВКА (АНГЛ.) (/) МАРКИРОВКА

1

09601-10002

PLATE, NAME,MACHINE SPEC.

2

04418-13060

SCREW

3

09133-A2321

PLATE, SAFETY,KEEP OUT OF TURNING AREA

4

203-00-31120

PLATE, INSTRUCTION,HYDRAULIC TANK

5

09653-A0361

PLATE, SAFETY,LEAVING SEAT

6

09653-A0481

PLATE, SAFETY,RADIATOR CAP

7

09805-C0881

PLATE, SAFETY,DO NOT STEP ON COVER

8

09669-0000E

PLATE, CAUTION,FUEL TANK

9

09667-A0481

PLATE, SAFETY,ENGINE STARTING

10

09963-A1640

TAG

11

09685-00001

PLATE, OPERATING,SAFETY LOCK LEVER

12

21U-98-31160

PLATE, MARK,CENTER OF GRAVITY

13

09808-A0881

PLATE, SAFETY,BATTERY CABLE

14

09134-A0881

PLATE, SAFETY,KEEP OUT OF WORKING AREA

15

21W-98-31820

PLATE,ENGINE OIL INLET

16

22L-98-18270

PLATE,URGENT ESCAPE

17

20Y-00-D1750

PLATE,COOLANT TEMPERATURE

18

20Y-00-D1760

PLATE,WATER TEMPERATURE

19

20Y-00-D1770

PLATE,ENGINE OIL TEMPERATURE

20

20Y-00-D1780

PLATE,FUEL TEMPERATURE

21

20Y-00-D1851

PLATE,HYDRAULIC TANK

22

201-98-81610

PLATE, CAUTION,COVER COUTION

23

201-98-81110

PLATE, MARK,OIL CONTROL

24

09845-00480

PLATE, SAFETY,CAUTION-BLAST SITE

25

20Y-00-31330

PLATE, OPERATING,EMERGENCY PUMP DRIVE SWITCH

26

14X-98-35181

PLATE,REFLECTOR

27

11Y-98-31130

PLATE,ECOT 3

28

201-98-89210

PLATE,PC70

29

201-98-81150

CHECK LIST,FIRE PREVENTION
