Запчасти Komatsu PC70-7E ОСНОВН. КЛАПАН (-КЛАПАН) (/)(№-7) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

723-26-11100

VALVE ASS'Y

|1

723-26-10104

VALVE ASS'Y

|1

723-26-10102

VALVE ASS'Y

|1

723-26-10101

VALVE ASS'Y

|1

CONTROL VALVE

|1

CONTROL VALVE

|1

CONTROL VALVE

1

BODY

2

BLOCK

3

BLOCK

4

BLOCK

5

BLOCK

|5

BLOCK

6

BLOCK

7

COVER

8

SPOOL

|8

SPOOL

9

SPOOL

10

SPOOL

|10

SPOOL

11

SPOOL

|11

SPOOL

12

SPOOL

13

PLUG

|13

PLUG

14

VALVE

|14

VALVE

15

PLUG

|15

PLUG

16

VALVE

17

SPRING

|17

SPRING

18

O-RING

19

723-26-15110

CASE

20

709-26-11450

SPRING

21

723-26-14210

SPRING

22

723-26-14122

SPRING

|22

723-26-14121

SPRING

23

723-26-15120

RETAINER

24

575-41-17420

O-RING

25

01252-30630

BOLT

26

01641-20608

WASHER
