Запчасти Komatsu PC70-7 ГЛАВН. КЛАПАН(№7-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

702-21-09155

VALVE ASS'Y

|1

702-21-09154

VALVE ASS'Y

|1

702-21-09153

VALVE ASS'Y

1

BLOCK

2

VALVE

3

SPRING

4

O-RING

5

O-RING

6

O-RING

7

702-21-53120

FILTER

8

07000-11009

O-RING

9

SPRING

10

PLATE

11

PLATE

12

01252-60820

BOLT

13

01643-50823

WASHER

14

O-RING

15

BLOCK

16

SPOOL

17

SLEEVE

18

SPRING

19

SCREW

|19

SCREW

20

SPRING

21

WASHER

22

722-10-71161

POPPET

|22

722-10-71160

POPPET

23

PLUG

24

07002-11423

O-RING

25

01582-11008

NUT

26

07000-11009

O-RING

27

07002-11023

O-RING

28

07002-11623

O-RING

29

SEAT

30

SPRING

31

04260-00793

BALL

32

07000-11009

O-RING

33

PLUG

34

ORIFICE

35

ORIFICE

36

01252-60520

BOLT

37

FRANGE

38

07000-12020

O-RING

39

01252-61025

BOLT

|40

702-21-55200

VALVE ASS'Y

40

SLEEVE

41

COLLAR

42

FILTER

43

POPPET

44

SPRING

45

SCREW

46

NUT

47

O-RING

48

702-16-53920

O-RING

49

O-RING

50

07002-11623

O-RING
