Запчасти Komatsu PC650LC-8E0 ПОРШЕНЬ НАСОС (ВНУТР. ЧАСТИ, NO. НАСОС) (/) H [ГИДРАВЛИКА]

|$1

708-2L-00772

PUMP ASSEMBLY

|$2

708-2L-01740

PUMP SUB ASS'Y

1

708-2L-22430

SHAFT, FRONT

2

708-2L-32150

BEARING

3

708-2E-05040

WASHER KIT

|$6

WASHER, T=3.1MM

|$7

WASHER, T=3.0MM

|$8

WASHER, T=2.9MM

|$9

WASHER, T=2.8MM

4

708-25-12790

RING,SNAP

5

708-25-52861

SEAL,OIL

6

708-25-12812

HOUSING

7

07000-A2080

O-RING

8

708-25-05130

SHIM KIT

|$15

SHIM, T=0.2MM

|$16

SHIM, T=0.1MM

9

01010-80820

BOLT

10

01643-30823

WASHER

|$19

708-2L-04151

BLOCK ASSEMBLY, REAR

11

BLOCK,CYLINDER

12

PLATE

13

720-68-19610

PIN

14

04065-04818

RING,SNAP

15

708-2L-23131

SEAT

16

708-2L-33160

SPRING

17

708-7L-13140

SEAT

18

708-2L-23351

GUIDE RETAINER, RETAINER

19

708-2L-23360

PIN

20

708-2L-33340

RETAINER, SHOE

21

708-2L-33310

PISTON SUBASSEMBLY
