Запчасти Komatsu PC650LC-8E0 ГУСЕНИЧНАЯ РАМА (С ПОЛН. LENGTH ЗАЩИТА ОПОРНЫХ КАТКОВ) (МОТОР ХОДА, ПРАВ.) (/) R [НИЖН.CARRIAGE]

|$1

21M-27-00070

FINAL DRIVE A. RH

|$2

706-8L-01110

MOTOR A.PC600-8(R.H)

1

706-88-40380

O-RING

2

07000-12012

O-RING

3

706-88-40310

BOLT

4

706-8L-41520

SHAFT DRIVE

5

706-88-40870

BEARING

6

706-88-40890

BEARING

7

706-88-40820

RETAINER

8

706-88-05010

SPACER KIT

|$11

706-88-40440

SPACER

|$12

706-88-40450

SPACER

|$13

706-88-40460

SPACER

9

04064-07525

SNAPRING

10

708-8K-12141

OIL SEAL

11

706-88-40710

HOUSING

12

07000-02135

O-RING

13

04071-00140

RING

14

706-8L-41370

SHAFT CENTER

15

706-8L-41270

RING CENTER

16

706-8L-41380

SPRING

17

706-8L-41260

RETAINER

18

708-23-12350

SCREW

19

706-8L-41610

PISTON SUB A.

20

706-88-90140

PLATE

21

706-88-90150

DISC

22

706-8L-91010

PISTON BRAKE

23

07000-15240

O-RING

24

706-88-90130

RING BACK-UP

25

07000-15270

O-RING

26

07001-05270

RING BACK UP

27

706-88-90420

SPRING
