Запчасти Komatsu PC650LC-8E0 МЕХАНИЗМ ПОВОРОТА И МОТОР (ВНУТР. ЧАСТИ, МОТОР ПОВОРОТА) (/) N [ПОВОРОТН. КРУГ И ITS КОМПОНЕНТЫ]

|$1

706-75-01461

SWING MOTOR A.

|$2

700-11-31960

PLATE

|$3

706-75-03451

MOTOR SUB A.

1

706-75-43680

SHAFT, DRIVE

2

706-75-43880

BEARING

3

706-75-43810

SPACER

4

706-7E-11260

SPRING

5

706-7E-11270

SEAT

6

706-76-40890

BEARING

7

706-75-05040

SPACER KIT

8

04064-04518

RING

9

706-75-43410

OIL SEAL

10

706-7G-41910

SPACER

11

04065-06220

RING

12

706-75-43190

BLOCK CYLINDER

13

706-75-43841

PLATE VALVE

14

706-75-43750

PIN DOWEL

15

706-75-43120

SHAFT, CENTER

16

706-75-43130

RING, CENTER

17

706-75-43140

SPRING

|$21

706-75-05020

RETAINER KIT

18

RETAINER

19

SCREW

20

706-75-43160

PISTON SUBASSEMBLY

21

706-75-92130

PLATE

22

706-75-92340

PLATE

23

706-75-92350

DISK

24

706-75-92380

PISTON BRAKE

25

706-75-92390

RING, BRAKE

26

07000-B2145

O-RING

27

706-7G-91530

O-RING

28

706-75-92360

SPRING
