Запчасти Komatsu PC650LC-8E0 ТРУБЫ СТРЕЛЫ (СТРЕЛА ANTI-DROP КЛАПАН) H [ГИДРАВЛИКА]

|$1

702-21-08250

VALVE A.A58

1

VALVE BODY

2

SPOOL

3

702-21-39410

CASE

4

702-21-39510

RETAINER

5

702-21-39430

FLANGE

6

702-21-39520

SPRING

7

702-21-39440

SPRING

8

709-62-31280

O-RING

9

702-21-39450

O-RING

10

702-21-39530

PLUG

11

01252-60840

BOLT,HEXAGON SOCKET HEAD

12

01252-60835

BOLT,HEXAGON SOCKET HEAD

13

01252-60820

BOLT,HEXAGON SOCKET HEAD

14

07000-13028

O-RING

15

702-21-39540

PLUG

16

700-93-11320

O-RING

17

700-93-11330

RING,BACK-UP

18

702-21-39550

BODY

19

702-21-39560

POPPET

20

702-21-39570

SPRING

21

702-21-39580

RETAINER

22

07000-12021

O-RING

23

07001-02021

RING,BACK-UP

24

700-22-11410

O-RING

25

700-80-64220

RING,BACK-UP

26

709-25-11390

O-RING

27

07000-13035

O-RING

28

01252-61065

BOLT

29

702-21-39590

SPACER
