Запчасти Komatsu PC650LC-8E0 ПРИВОД НАСОС (НАСОС ВЕНТИЛЯТОРА) (/7) H [ГИДРАВЛИКА]

|$1

708-1U-00202

PUMP A. PC600(FAN)

|$2

708-1U-00213

PUMP A.

|$3

708-1U-01218

PUMP SUB A.

|$4

708-1U-04143

CASE A.

1

708-1U-11143

CASE PUMP

2

708-21-12541

PLUG

3

708-1W-44311

SLEEVE

4

708-1W-44220

RING

5

708-8E-16160

PLUG

6

07002-11023

O-RING

7

07040-12412

PLUG

8

07002-12434

O-RING

9

706-73-42370

O-RING

10

07000-B1009

O-RING

11

708-1L-29340

ORIFICE

12

04020-01024

PIN

13

01010-61470

BOLT

14

01643-31445

WASHER

15

708-1U-11562

CAP END

16

708-1W-42120

BEARING

17

708-1U-13461

BALL RETAINER

18

708-1U-13450

CAM ROCKER

19

04260-01270

BALL

20

708-1U-12120

SHAFT

21

708-1W-42110

BEARING

22

708-1W-42140

CASE OIL SEAL

23

708-1W-42130

OIL SEAL

24

07000-B2060

O-RING

25

708-1W-05821

SPACER KIT

|$30

708-1W-42430

SPACER

|$31

708-1W-42530

SPACER

|$32

708-1W-42440

SPACER

|$33

708-1W-42540

SPACER

|$34

708-1W-42450

SPACER

|$35

708-1W-42550

SPACER

|$36

708-1W-42460

SPACER

|$37

708-1W-42560

SPACER

|$38

708-1W-42470

SPACER

26

04065-06825

RING
