Запчасти Komatsu PC650LC-8E0 ПОРШЕНЬ НАСОС (ВНУТР. ЧАСТИ, NO. НАСОС) (8/9) H [ГИДРАВЛИКА]

|$1

708-2L-90723

PUMP ASSEMBLY

|$2

708-25-08292

VALVE ASSEMLBY,SERVO,REAR

|$3

708-25-00830

BODY ASSY

1

BODY, FRONT

2

EXPANDER

3

708-25-15120

PISTON

4

708-25-15130

SEAT

5

708-25-55250

SPRING

6

708-25-25130

SPRING

7

708-23-15160

PLUG

8

708-23-15120

SEAT

9

07000-B2018

O-RING

10

708-25-15150

COVER

11

01580-10806

NUT

12

01252-60616

BOLT

13

01602-20619

WASHER

14

07002-62034

O-RING

15

07239-12009

NUT

16

708-25-15180

SLEEVE

17

708-25-15280

SPOOL

18

708-25-15310

SPRING

19

708-25-15330

SPACER

20

708-25-15171

PLUG

21

708-25-15340

SCREW

22

07000-B2012

O-RING

23

708-25-15250

COVER

24

01580-10806

NUT

25

01252-60616

BOLT

26

01602-20619

WASHER

27

708-25-15260

PLUG

28

07002-60823

O-RING

29

708-25-15270

ARM

30

708-25-15360

PIN

31

708-25-15370

WASHER

32

708-25-15380

E-RING

33

07040-11007

PLUG

34

07002-61023

O-RING

35

708-25-55110

PLATE

36

708-25-19250

PLUG

37

708-2L-25490

O-RING
