Запчасти Komatsu PC650LC-8E0 ПОРШЕНЬ НАСОС (ВНУТР. ЧАСТИ, NO. НАСОС) (/9) H [ГИДРАВЛИКА]

|$1

708-2L-90723

PUMP ASSEMBLY

|$2

708-2L-01750

PUMP SUB ASS'Y

|$3

708-2L-04940

CASE ASSEMBLY, REAR

1

CASE, REAR

2

PLUG

3

07044-12412

PLUG

4

07002-62434

O-RING

5

708-2L-21870

CAP,END

6

708-2L-32260

BEARING

7

07000-B2135

O-RING

8

6130-21-1910

PIN DOWEL

9

07000-B2012

O-RING

10

708-2L-41270

O-RING

11

07000-B1009

O-RING

12

07000-B5165

O-RING

13

07000-B3032

O-RING

14

708-25-12530

BOLT

15

04530-11018

EYE-BOLT

16

708-25-13630

RING

17

708-2L-22440

SHAFT, REAR

18

708-2L-32150

BEARING

19

708-2E-05040

WASHER KIT

|$23

WASHER, T=3.1MM

|$24

WASHER, T=3.0MM

|$25

WASHER, T=2.9MM

|$26

WASHER, T=2.8MM

20

708-25-12790

RING SNAP

21

708-25-05021

SHIM KIT

|$29

SHIM, T=0.5MM

|$30

SHIM, T=0.2MM

|$31

SHIM, T=0.15MM

|$32

SHIM, T=0.1MM

22

708-25-12950

PLATE

23

706-74-40320

BOLT

24

01643-31032

WASHER

25

01252-31016

BOLT

26

708-25-05130

SHIM KIT

|$38

SHIM, T=0.2MM

|$39

SHIM, T=0.1MM
