Запчасти Komatsu PC650LC-8E0 ПОРШЕНЬ НАСОС (ВНУТР. ЧАСТИ, NO. НАСОС) (/9) H [ГИДРАВЛИКА]

|$1

708-2L-90723

PUMP ASSEMBLY

|$2

708-2L-01750

PUMP SUB ASS'Y

|$3

708-2L-04930

CASE ASSEMBLY, FRONT

1

CASE, FRONT

2

PLUG

3

07044-12412

PLUG

4

07002-62434

O-RING

5

708-2L-21880

CAP,END

6

708-2L-32260

BEARING

7

07000-B2135

O-RING

8

6130-21-1910

PIN DOWEL

9

07000-B2012

O-RING

10

708-2L-41270

O-RING

11

07000-B1009

O-RING

12

07000-B3032

O-RING

13

708-25-12530

BOLT

14

01141-81620

STUD

15

01643-31645

WASHER

16

01582-01613

NUT

17

01140-81645

STUD

18

01643-31645

WASHER

19

01582-01613

NUT

20

720-68-19610

PIN

21

04530-11018

EYE-BOLT

22

708-25-13630

RING
