Запчасти Komatsu PC650LC-8E0 МЕХАНИЗМ ПОВОРОТА И МОТОР, ЛЕВ. (№-) МЕХАНИЗМ ПОВОРОТА И МОТОР

1

01010-81460

Bolt

2

01643-31445

Washer, Flat

3

22U-26-21280

Ring

4

07049-01822

Plug

5

21M-26-21170

Case

6

06000-22222

Bearing

7

06000-22324

Bearing

8

207-26-54263

Cover

9

01010-81040

Bolt

10

01643-31032

Washer

11

207-26-61210

Seal

12

21M-26-11180

Shaft

13

207-26-62150

Coupling

14

207-26-54230

Plate

15

205-32-51211

Bolt

16

20Y-27-22170

Carrier

17

20Y-27-22140

Gear

18

20Y-27-22220

Bearing

19

20Y-27-21250

Washer, Thrust

20

20Y-27-21230

Pin

21

20Y-27-21290

Pin

22

207-26-62190

Gear

23

20Y-27-13310

Washer, Thrust

24

20Y-27-22240

Washer, Thrust

25

21M-26-11261

Gear

26

21M-26-11150

Carrier

27

21M-26-11140

Gear

28

20Y-27-22210

Bearing

29

20Y-27-21240

Washer, Thrust

30

20Y-27-21220

Pin

31

20Y-27-21280

Pin

32

21M-26-11190

Plate

33

21M-26-21130

Gear

34

20Y-27-21310

Washer

35

21M-26-11161

Cover

36

20Y-27-13281

Bolt

37

01643-31645

Washer

38

208-27-61350

Button

39

20Y-27-22280

O-ring

40

07049-02430

Plug

41

21M-26-11270

Elbow

42

02896-11018

O-ring

43

02782-10628

Elbow

44

02896-11018

O-ring

45

02762-006A4

Hose

46

07730-50004

Valve, Drain

47

07002-12434

O-ring

48

21M-26-21180

Gauge

49

21M-26-21220

Filler
