Запчасти Komatsu PC650LC-8E0 ПОРШЕНЬ НАСОС, ВНУТР. ЧАСТИ, NO. НАСОС (/) (№-) ПОРШЕНЬ НАСОС

|$0

708-2L-00771

Pump Assembly

|$1

708-25-85271

Valve Assembly, Servo,Rear

|$2

708-25-85471

Valve Subassembly, Servo,Rear

|$3

708-25-00840

Body Assembly

1

Body

2

Expander

3

708-25-15120

Piston

4

708-25-15130

Seat

5

708-25-55250

Spring

6

708-25-25130

Spring

7

708-23-15160

Plug

8

708-23-15120

Seat

9

07000-B2018

O-ring

10

708-25-15150

Cover

11

01580-10806

Nut

12

01252-60616

Bolt, Hexagon Socket Head

13

01602-20619

Washer

14

708-25-55680

Plug

15

02789-00315

Plug

16

02896-61009

O-ring

17

07002-62034

O-ring

18

07239-12009

Nut

19

708-25-15180

Sleeve

20

708-25-15280

Spool

21

708-25-15310

Spring

22

708-25-15330

Spacer

23

708-25-15430

Plug

24

708-25-15340

Screw

25

07000-B2012

O-ring

26

708-25-15250

Cover

27

01580-10806

Nut

28

01252-60616

Bolt, Hexagon Socket Head

29

01602-20619

Washer

30

708-25-15260

Plug

31

07002-60823

O-ring

32

708-25-15270

Arm

33

708-25-15360

Pin

34

708-25-15370

Washer

35

708-25-15380

E-ring
