Запчасти Komatsu PC650LC-8E0 ПРОТИВОВЕС REMOVER, ШЛАНГИ (№-) ПРОТИВОВЕС REMOVER

Схема запчастей Komatsu PC650LC-8E0 - ПРОТИВОВЕС REMOVER, ШЛАНГИ (№-) ПРОТИВОВЕС REMOVER
1
4
5
7
9
11
20
18
1
2
9
8
10
12
21
16
13
14
2
3
6
8
12
10
3
4
11
5
7
6
15
18
17
13
19
23
24
22
20
14
24
19
22
21
17
16
15
23
25
26
27
28
29
30
31
32

Артикул

Название

Примечание

Количество

1

21M-62-33210

Hose Assembly

2

20Y-62-22820

Band, Blue

3

21M-62-33130

Hose Assembly

4

20Y-62-22850

Band, Green

5

21M-62-33140

Hose Assembly

6

20Y-62-22810

Band, Yellow

7

21M-62-33120

Hose Assembly

8

20Y-62-22860

Band, Brown

9

21M-62-33150

Hose Assembly

10

20Y-62-22830

Band, White

11

21M-62-33230

Hose Assembly

12

20Y-62-22790

Band, Red

13

21M-62-33110

Hose Assembly

14

20Y-62-22820

Band, Blue

15

21M-62-33220

Hose Assembly

16

20Y-62-22850

Band, Green

17

21M-62-33180

Hose Assembly

18

20Y-62-22810

Band, Yellow

19

21M-62-33240

Hose Assembly

20

20Y-62-22830

Band, White

21

21M-62-33160

Hose Assembly

22

20Y-62-22860

Band, Brown

23

21M-62-33170

Hose Assembly

24

20Y-62-22790

Band, Red

25

21M-62-33190

Hose Assembly

26

21M-62-33250

Hose Assembly

27

02757-003A3

Hose

28

02789-10315

Plug

29

07376-70315

Plug

30

02896-61009

O-ring

31

08034-20536

Band

32

21M-62-22150

Hose

Выбрано товаров: 32
