Запчасти Komatsu PC650LC-8E0 ОСНОВН. ПОРШЕНЬ НАСОС, ВНУТР. ЧАСТИ, NO. НАСОС (8/9) (№-) ОСНОВН. ПОРШЕНЬ НАСОС

|$0

708-2L-90721

Pump Assembly

|$1

708-25-08291

Valve Assembly, Servo,Rear

|$2

708-23-00411

Body Assembly

1

Body,Front

2

Expander

3

708-25-15120

Piston

4

708-25-15130

Seat

5

708-25-55250

Spring

6

708-25-25130

Spring

7

708-23-15160

Plug

8

708-23-15120

Seat

9

07000-12018

O-ring

10

708-25-15150

Cover

11

01580-10806

Nut

12

01252-60616

Bolt, Hexagon Socket Head

13

01602-20619

Washer

14

07002-12034

O-ring

15

07239-12009

Nut

16

708-25-15180

Sleeve

17

708-25-15280

Spool

18

708-25-15310

Spring

19

708-25-15330

Spacer

20

708-25-15171

Plug

21

708-25-15340

Screw

22

07000-12012

O-ring

23

708-25-15250

Cover

24

01580-10806

Nut

25

01252-60616

Bolt, Hexagon Socket Head

26

01602-20619

Washer

27

708-25-15260

Plug

28

07002-10823

O-ring

29

708-25-15270

Arm

30

708-25-15360

Pin

31

708-25-15370

Washer

32

708-25-15380

E-ring

33

07040-11007

Plug

34

07002-11023

O-ring

35

708-25-55110

Plate

36

708-25-19290

Plug

37

07000-12010

O-ring

38

07000-12011

O-ring

39

01010-80825

Bolt

40

01643-50823

Washer

41

708-25-19150

Orifice

42

720-68-11920

Filter

43

07000-12010

O-ring

44

07000-11009

O-ring

45

07000-13048

O-ring

46

708-25-15430

Plug

47

708-25-15460

Shim, T=0.05mm

47

708-25-15470

Shim, T=0.10mm
