Запчасти Komatsu PC650LC-6 МЕХАНИЗМ ПОВОРОТА (ПРАВ.)(№-) ПОВОРОТН. КРУГ И КОМПОНЕНТЫ

1

706-75-01251

MOTOR ASS'Y

2

01010-81460

BOLT

3

01643-31445

WASHER

4

20Y-26-22270

RING

5

07049-01822

PLUG

6

07042-30108

PLUG

7

21M-26-11170

CASE

8

06000-22222

BEARING

9

06000-22324

BEARING

10

207-26-54263

COVER

11

01010-81040

BOLT

12

01643-31032

WASHER

13

207-26-61210

SEAL

14

21M-26-11180

SHAFT

15

207-26-62150

COUPLING

16

207-26-54230

PLATE

17

205-32-51211

BOLT

18

20Y-27-22170

CARRIER

19

20Y-27-22140

GEAR

20

20Y-27-22220

BEARING

21

20Y-27-21250

WASHER

22

20Y-27-21230

PIN

23

20Y-27-21290

PIN

24

207-26-62190

GEAR

25

20Y-27-13310

WASHER

26

20Y-27-22240

WASHER

27

207-26-62130

GEAR

28

21M-26-11150

CARRIER

29

21M-26-11140

GEAR

30

20Y-27-22210

BEARING

31

20Y-27-21240

WASHER

32

20Y-27-21220

PIN

33

20Y-27-21280

PIN

34

21M-26-11190

PLATE

35

21M-26-11130

GEAR

36

20Y-27-21310

WASHER

37

21M-26-11160

COVER

38

20Y-27-13281

BOLT

39

01643-31645

WASHER

40

207-27-61280

BUTTON

41

209-26-51280

ELBOW

42

07235-10628

ELBOW

43

07103-20604

HOSE

44

07730-50004

VALVE

45

07002-12434

O-RING

46

21M-26-11210

GAUGE

47

21M-26-11220

FILLER
