Запчасти Komatsu PC650-5 ПОВОРОТН. КЛАПАН (/) ГИДРАВЛИКА
№
Артикул
Название
Примечание
Количество
|1
700-91-36001
VALVE ASS'Y
|1
700-91-36000
VALVE ASS'Y
|1
700-92-55000
RELIEF VALVE ASS'Y
1
SLEEVE
2
VALVE
3
SPRING
4
PLUG
5
SEAT
6
O-RING
7
RING,BACK-UP
8
POPPET
9
SPACER
10
SPRING
11
RETAINER
12
HOLDER
13
NUT
14
O-RING
15
SCREW
16
NUT
17
NUT
18
WASHER
19
700-93-11320
O-RING
20
700-93-11330
RING,BACK-UP
21
07002-03634
O-RING
|22
700-90-62002
VALVE ASS'Y
|22
700-90-62000
VALVE ASS'Y
22
SLEEVE
23
VALVE
24
SPRING
25
PLUG
26
O-RING
27
700-93-11320
O-RING
28
700-93-11330
RING,BACK-UP
29
07002-03634
O-RING
|30
700-90-99000
VALVE ASS'Y
30
700-93-12651
BODY
31
700-93-12660
ORIFICE
32
709-90-91110
SENSOR
33
07000-02014
O-RING
34
07002-02434
O-RING
|35
709-10-55202
VALVE ASS'Y
|35
709-10-55201
VALVE ASS'Y
|35
709-10-55200
VALVE ASS'Y
35
SLEEVE
36
VALVE
37
SPRING
38
PLUG
39
SEAT
40
O-RING
41
POPPET
42
SPRING
43
HOLDER
44
NUT
45
O-RING
46
SCREW
|46
709-10-51371
SCREW
|46
709-10-51370
SCREW
47
NUT
48
O-RING
49
700-93-11320
O-RING
50
700-93-11330
RING,BACK-UP
51
07002-03634
O-RING
52
700-93-11350
PLUG
53
700-93-11320
O-RING
54
700-93-11330
RING
55
07002-03634
O-RING
Выбрано товаров: 66
