Запчасти Komatsu PC650-5 & PC650LC-5 ТОПЛИВН. БАК. С БЛОКИР.ING КРЫШКА, ТОПЛИВН. БАК. ТРУБЫ И ТОПЛИВН. УРОВЕНЬ ДАТЧИК ТОПЛИВН. БАК. AND КОМПОНЕНТЫ

|$0

209-04-51112

TANK ASSEMBLY, FUEL

1

NSS

TANK, FUEL

2

07091-21200

CAP, FUEL

3

07056-18416

STRAINER, FUEL

4

208-04-19130

ELBOW

5

208-04-19160

BALL, FLOAT

6

203-60-31160

TUBE

7

07000-05170

O-RING

8

209-04-61110

FLANGE

9

01010-51235

BOLT

10

01643-31232

WASHER

11

01010-52045

BOLT

12

01643-32060

WASHER

13

07000-02085

O-RING

14

7861-92-4800

SENSOR, FUEL LEVEL

15

209-09-A1110

CLIP

16

01010-51016

BOLT

17

01643-31032

WASHER

18

07700-40460

VALVE, FUEL SHUT-OFF

19

07238-10522

CONNECTOR

20

07102-20541

HOSE, FROM FUEL TANK TO ENGINE

21

01010-51225

BOLT

22

01643-31232

WASHER

23

08036-02514

CLIP

24

205-62-53461

ELBOW

25

07102-20344

HOSE, ENGINE TO FUEL TANK

26

209-09-A1110

CLIP

27

01010-51225

BOLT

28

01643-31232

WASHER

29

198-03-16640

CLIP

30

01010-51225

BOLT

31

01643-31232

WASHER

32

6721-71-9780

ADAPTER

33

209-04-11150

JOINT

34

209-04-51140

ELBOW

35

01010-51225

BOLT

36

01643-31232

WASHER

37

07700-40460

VALVE, FUEL SHUT-OFF

38

154-04-12480

NIPPLE

39

09480-10100

CLAMP

40

209-04-11240

TUBE

41

07102-20409

HOSE, FUEL TANK TO SHUT-OFF VALVE

42

140-06-18440

CLIP

43

01010-51225

BOLT

44

01643-31232

WASHER

45

08036-02514

CLIP

46

01010-51225

BOLT

47

01643-31232

WASHER
