Запчасти Komatsu PC650-5 & PC650LC-5 ТУРБОНАГНЕТАТЕЛЬ ДВИГАТЕЛЬ

|$0

1241 565 H91

KIT, TURBO

1

1238 594 H1

GASKET, CONNECTION

2

1252 716 H1

GASKET, CONNECTION

3

1238 764 H1

GASKET, TURBOCHARGER

4

1252 177 H1

O-RING

5

1239 056 H1

SEAL, DUST

|$6

1241 648 H91

TURBOCHARGER

6

NSS

HOUSING, COMPRESSOR

7

1241 398 H1

CLAMP, V-BAND

8

1241 387 H1

NUT, LOCK

9

NSS

IMPELLER, TURBO COMPRESSOR

10

1241 409 H1

BOLT

11

1241 385 H1

WASHER, PLAIN

12

1241 408 H1

DIFFUSER, TURBOCHARGER

13

1240 489 H1

O-RING

14

1241 401 H1

SEAL, SPLIT RING

15

1241 404 H1

SLINGER, OIL

16

1241 406 H1

BAFFLE, OIL

17

1241 405 H1

SHIM

18

1242 024 H1

BEARING, TURBO THRUST

19

1241 388 H1

COLLAR, THRUST

20

1241 390 H1

RING, RETAINING

21

1241 389 H1

BEARING, TURBOCHARGER

22

1241 402 H1

HOUSING, TURBO BEARING

23

1241 391 H1

SHIELD, TURBOCHARGER HEAT

24

1241 393 H1

BOLT

25

1241 395 H1

SEAL, SPLIT RING

26

1241 392 H1

SHAFT & WHEEL

27

1241 552 H2

HOUSING, TURBINE

28

1240 491 H1

NUT, HEX

29

1241 399 H1

LOCKPLATE

N/I

NSS

DATAPLATE

|$32

1246 471 H1

SCREW, DRIVE

|$33

1242 019 H91

KIT, TURBO BEARING, SEAL
