Запчасти Komatsu PC650-5 & PC650LC-5 CRANKING МОТОР заводской номер A THRU A КОМПОНЕНТЫ ДВИГАТЕЛЯ

|$0

739 912 C91

MOTOR ASSEMBLY, CRANKING

1

1211 480 H91

HOUSING ASSEMBLY, DRIVE END

2

1211 288 H1

BUSHING, HOUSING

3

1211 276 H1

WICK, OIL

4

1211 277 H1

PLUG, WICK

|$5

20 499 R1

BOLT, MOUNTING - 5/16NCx1-1/2

|$6

21 241 R1

BOLT, MOUNTING - 5/16NCx7/8

5

1223 259 H1

DRIVE, MOTOR

6

1211 289 H1

LEVER, SHIFT

7

1211 287 H1

GASKET, BETWEEN HOUSINGS

8

1211 286 H1

WASHER, BRAKE

9

1211 284 H1

PLUG, HOUSING

10

1211 283 H1

BUSHING, LEVER HOUSING

11

NSS

HOUSING, SHIFT LEVER

|$14

NSS

BOLT, MOUNTING - 1/4NCx1

12

1210 066 H1

COVER, INSPECTION

13

1211 151 H1

GASKET, COVER

14

1211 277 H1

PLUG, WICK

15

1211 276 H1

WICK, OIL

16

213 262 R1

RING, RETAINING

17

355 967 R1

O-RING

18

1211 152 H1

SHAFT, SHIFT LEVER

19

352 219 R1

O-RING

20

1211 282 H1

CABLE, SOLENOID TO COMMUTATOR END

21

1211 398 H1

SWITCH, SOLENOID

|$25

113 955

BOLT AND WASHER

22

1211 290 H1

PLUNGER, SOLENOID

|$27

19 839 R1

NUT, LOCK - 5/16NF

23

1210 070 H1

WASHER, RETAINER

24

1211 291 H1

BOOT, PLUNGER

25

1210 072 H1

RETAINER, SPRING

26

1210 073 H1

SPRING, PLUNGER

27

1210 074 H1

RETAINER, SPRING

28

22 411 R1

O-RING

29

1211 285 H1

SEAL, SHAFT OIL

30

1211 356 H1

SPACER, SHAFT

31

1211 271 H1

INSULATOR, TRIANGULAR

32

NSS

SHOE, POLE

|$37

1211 150 H1

SCREW, SHOE

33

1211 397 H1

COIL, FIELD (6 COILS)

34

1211 269 H1

STUD, TERMINAL

35

1211 264 H1

KIT, TERMINAL

36

1211 265 H1

WASHER, STUD - INSULATED

37

1211 266 H1

WASHER, STUD - PLAIN

38

NSS

NUT, TERMINAL - 1/2NC

39

NSS

CONNECTOR, TERMINAL TO SWITCH

40

1211 267 H1

NUT AND WASHER, TERMINAL STUD

41

NSS

INSULATOR, FIELD COIL

42

1211 396 H1

ARMATURE

43

1211 402 H1

WASHER, THRUST

44

1211 395 H1

BUSHING, COMMUTATOR END FRAME

45

1211 292 H1

SCREW, FIELD COIL

46

1211 401 H91

PLATE ASSEMBLY,BRUSH

47

1211 400 H1

SPRING, BRUSH

|$53

1211 279 H1

SCREW, ATTACHING

48

1211 399 H1

BRUSH

|$55

1211 292 H1

SCREW, BRUSH

49

1211 280 H1

WASHER, STUD - INSULATED

50

NSS

FRAME, COMMUTATOR END

|$58

NSS

BOLT, MOUNTING - 1/2NCx1

51

1211 281 H1

KIT, TERMINAL

52

NSS

WASHER, LOCK - 1/2
