Запчасти Komatsu PC650-5 & PC650LC-5 МЕХАНИЗМ ПОВОРОТА РЕМ. КОМПЛЕКТЫ

|$0

209-26-00021

SWING MACHINERY ASSEMBLY

1

209-26-51111

CASE

2

06030-23234

BEARING

3

21T-26-11510

SPACER

4

21T-26-11270

RING, SNAP

5

21T-26-11260

SEAL, OIL

6

209-26-51240

COVER

7

01010-51030

BOLT

8

01643-31032

WASHER

9

07049-03038

PLUG

10

209-26-52100

CARRIER, PLANET

11

04020-00616

PIN, DOWEL

12

209-26-51220

WASHER, THRUST

13

21T-26-11180

GEAR, PLANET

14

21T-26-11230

BEARING

15

21T-26-11220

WASHER, THRUST

16

209-26-51150

PIN

17

195-27-12160

LOCK

18

01010-31225

BOLT

19

21T-26-11260

SEAL, OIL

20

209-26-52130

GEAR

21

04020-01228

PIN

22

07000-05070

O-RING

23

07000-05160

O-RING

24

21T-26-11250

HOLDER

25

01011-63040

BOLT

26

01643-33080

WASHER

27

209-26-51131

GEAR, RING

28

209-26-51170

SHAFT

29

04020-00616

PIN, DOWEL

30

209-26-51180

COLLAR

31

06043-00232

BEARING

32

209-26-51121

CASE

33

01011-51620

BOLT

34

01643-31645

WASHER

35

07049-01620

PLUG

36

209-26-51140

GEAR, RING

37

209-26-51190

CARRIER, PLANET

38

21T-26-11330

HOLDER

39

04020-00616

PIN

40

21T-26-11340

WASHER, THRUST

41

209-26-11190

GEAR, PLANET

42

21T-26-11380

BEARING

43

21T-26-11390

WASHER, THRUST

44

209-26-51160

PIN

45

21T-26-11420

LOCK

46

01010-31225

BOLT

47

01010-51640

BOLT

48

209-26-53162

SHAFT

49

04020-00616

PIN, DOWEL

50

209-26-51230

WASHER, THRUST

51

209-26-53111

COVER

52

01010-31270

BOLT

53

01643-31232

WASHER

54

07049-01215

PLUG

55

07049-03038

PLUG

56

209-26-51250

TUBE

57

07000-03035

O-RING

58

01010-51445

BOLT

59

01643-31445

WASHER

60

209-26-51260

GAUGE

61

07000-03022

O-RING

62

07102-20304

HOSE

63

07232-20315

ELBOW

64

07239-12009

NUT

65

07002-32034

O-RING

66

209-26-51271

BRACKET

67

07283-23442

CLIP

68

01599-01011

NUT

69

01643-31032

WASHER

70

01010-31225

BOLT

71

01643-31232

WASHER

72

07239-12009

NUT

73

07002-32034

O-RING

74

07232-20315

ELBOW
