Запчасти Komatsu PC650-5 & PC650LC-5 ЦИЛИНДР КОВША РАБОЧЕЕ ОБОРУДОВАНИЕ
№
Артикул
Название
Примечание
Количество
|$0
209-63-02130
CYLINDER ASSEMBLY, BUCKET
1
209-63-72540
CYLINDER
2
707-46-13010
BUSHING
3
07043-00180
PLUG
4
707-28-18550
HEAD, CYLINDER
5
707-51-13130
PACKING, ROD
6
707-51-13630
RING, BUFFER
7
707-52-91050
BUSHING
8
707-56-13520
SEAL, DUST
9
07179-14146
RING
10
07000-15175
O-RING
11
707-35-91850
RING, BACK-UP
12
07000-15175
O-RING
13
07001-05175
RING, BACK-UP
14
707-71-31360
COLLAR
15
707-71-11350
RING
16
01010-32495
BOLT
17
707-88-75410
WASHER
18
209-63-72520
ROD
19
707-46-11520
BUSHING
20
07043-00108
PLUG
|$21
707-91-01812
PISTON ASSEMBLY
21
707-37-18011
PISTON
22
130-63-12464
SEAT
23
707-83-11060
VALVE
24
707-80-11210
SPRING
25
707-83-11100
VALVE, PISTON
26
707-71-91410
SPACER
27
07000-12110
O-RING
28
707-35-52950
RING, BACK-UP
29
707-39-18820
RING, WEAR
30
707-44-18180
RING, PISTON
31
707-40-18970
SPACER
32
707-37-18020
PISTON
33
707-71-61310
PLUNGER
34
01252-31485
BOLT
35
209-62-68160
TUBE
36
209-62-68170
TUBE
37
07000-13038
O-RING
38
01010-31245
BOLT
39
01643-31232
WASHER
40
07000-13038
O-RING
41
07378-11210
HEAD
42
07371-51260
FLANGE
43
01010-31245
BOLT
44
01643-31232
WASHER
45
707-88-96050
BAND
46
209-62-68190
BRACKET
47
209-62-68180
BAND
48
01010-51240
BOLT
49
01643-31232
WASHER
50
07283-33442
CLIP
51
01599-01011
NUT
52
01643-31032
WASHER
|$57
707-99-69600
SERVICE KIT, BUCKET CYLINDER
|$58
707-51-13130
PACKING, ROD
|$59
707-51-13630
RING, BUFFER
|$60
707-56-13520
SEAL, DUST
|$61
07000-15175
O-RING
|$62
707-35-91850
RING, BACK-UP
|$63
07000-15175
O-RING
|$64
07001-05175
RING, BACK-UP
|$65
07000-12110
O-RING
|$66
707-35-52950
RING, BACK-UP
|$67
707-39-18820
RING, WEAR
|$68
707-44-18180
RING, PISTON
|$69
07000-13038
O-RING
Выбрано товаров: 67
