Запчасти Komatsu PC650-5 & PC650LC-5 ЦИЛИНДР СТРЕЛЫ РАБОЧЕЕ ОБОРУДОВАНИЕ

|$0

209-63-02100

CYLINDER ASSEMBLY, BOOM

1

209-63-52540

CYLINDER

2

707-46-13010

BUSHING

3

07043-00108

PLUG

4

707-28-20710

HEAD, CYLINDER

5

707-51-14130

PACKING, ROD

6

707-51-14630

RING, BUFFER

7

707-52-91150

BUSHING

8

198-63-93170

SEAL, DUST

9

07179-14160

RING, SNAP

10

07000-15195

O-RING

11

707-35-92050

RING, BACK-UP

12

07000-15195

O-RING

13

07001-05195

RING, BACK-UP

14

707-71-31460

COLLAR

15

707-71-11450

RING

16

01011-82700

BOLT

17

01643-32780

WASHER

18

209-63-52520

ROD

19

707-46-11520

BUSHING

20

07043-00108

PLUG

|$21

707-91-02062

PISTON ASSEMBLY

21

707-37-20031

PISTON

22

175-63-12650

SEAT

23

707-83-10140

VALVE

24

707-80-11610

SPRING

25

707-83-10200

VALVE

26

07000-12115

O-RING

27

707-35-52860

RING, BACK-UP

28

707-39-20820

RING, WEAR

29

707-44-20180

RING, PISTON

30

707-40-20970

SPACER

31

707-37-20020

PISTON

32

707-71-61410

PLUNGER

33

01252-41490

BOLT

34

209-63-52570

TUBE, L.H

|$39

209-63-52670

TUBE, R.H

35

209-62-58180

TUBE, L.H

|$41

209-62-58190

TUBE, R.H

36

07000-13038

O-RING

37

01010-31245

BOLT

38

01643-31232

WASHER

39

07378-11210

HEAD

40

07371-51260

FLANGE

41

01010-31245

BOLT

42

01643-31232

WASHER

43

707-88-96110

BAND

44

707-88-96120

BAND

45

01010-51240

BOLT

46

01643-31232

WASHER

47

07283-33442

CLIP

48

01599-01011

NUT

49

01643-31032

WASHER

|$56

707-99-77220

SERVICE KIT, BOOM CYLINDER

|$57

707-51-14130

PACKING, ROD

|$58

707-51-14630

RING, BUFFER

|$59

198-63-93170

SEAL, DUST

|$60

07000-15195

O-RING

|$61

707-35-92050

RING, BACK-UP

|$62

07000-15195

O-RING

|$63

07001-05195

RING, BACK-UP

|$64

07000-12115

O-RING

|$65

707-35-52860

RING, BACK-UP

|$66

707-39-20820

RING, WEAR

|$67

07000-13038

O-RING
