Запчасти Komatsu PC650-5 & PC650LC-5 ТОПЛИВН. НАСОС КОЖУХ ДВИГАТЕЛЬ

|$0

1267 763 H91

HOUSING, FUEL PUMP

1

1267 764 H1

BODY, FUEL PUMP

2

1238 170 H1

SLEEVE, SPRING PACK

3

1238 613 H1

HOUSING, SPRING PACK

4

1238 887 H1

BALL, PLUG AFC

5

1238 137 H1

BUSHING, TACHOMETER DRIVE

6

1238 209 H1

DOWEL, RING

7

NSS

BARREL, GOVERNOR UPPER

8

1238 949 H1

BARREL, GOVERNOR LOWER

|$9

1241 340 H91

PLUNGER, GOVERNOR

9

1240 057 H1

DRIVER, GOVERNOR PLUNGER

10

1241 339 H1

PLUNGER, GOVERNOR

11

1239 551 H1

BEARING, THRUST

12

1250 107 H1

SPACER, BEARING

|$14

1237 932 H91

PLUNGER, GOVERNOR

9

1240 057 H1

DRIVER, GOVERNOR PLUNGER

13

1238 856 H1

PLUNGER, GOVERNOR

14

1239 683 H1

BEARING, THRUST

15

1238 141 H1

O-RING

16

1238 392 H1

RING, RETAINING

17

1238 883 H1

O-RING

18

1239 114 H2

SCREW, FUEL PUMP ADJUSTING

|$22

1294 268 H91

ASSEMBLY, THROTTLE SHAFT

19

1239 118 H1

STOP, THROTTLE LEVER

20

1239 119 H1

SCREW, SET

21

1239 829 H1

SHAFT, THROTTLE

22

1238 591 H1

PLUG, FUEL SCREEN RETURN

23

1238 322 H1

O-RING

24

1238 249 H1

RING, RETAINING

25

1238 338 H1

SCREEN, FILTER

26

1240 058 H1

SPRING, COMPRESSION

27

NSS

SPRING, COMPRESSION

28

1238 323 H1

O-RING

29

90 897

O-RING

30

1240 007 H1

O-RING

31

1239 096 H1

PLATE, COVER

32

1238 977 H1

PLUG, BARREL

33

1240 069 H1

SCREW, SPRINGTITE

35

1238 053 H1

RING, RETAINING

36

1239 557 H1

GASKET, PLATE

37

1238 884 H1

PLUG, BALL

38

1238 978 H1

COVER, FUEL CONTROL

39

NSS

NAMEPLATE

40

1239 515 H1

PLUG, PIPE

41

1239 824 H1

SCREW, SOCKET SET

42

1246 109 H1

SCREW, DRIVE

43

1238 184 H1

NUT, FUEL PUMP ADJUSTING

44

1238 144 H1

SHIM - 0.005 IN

|$48

1238 145 H1

SHIM - 0.010 IN

|$49

1238 146 H1

SHIM - 0.020 IN

|$50

1239 086 H1

PLUG, O-RING
