Запчасти Komatsu PC650-5 & PC650LC-5 КАПОТ С ЗАЩИТА ОТ ВАНДАЛИЗМА ЧАСТИ КОРПУСА

1

209-54-64310

HOOD

2

209-54-56441

SEAL

3

209-54-56451

SEAL

4

209-54-54320

COVER

5

205-54-64160

HINGE (WELDED)

6

209-54-54330

COVER

7

205-54-64160

HINGE (WELDED)

8

21N-54-11130

COVER

9

01010-51230

BOLT

10

01643-31232

WASHER

11

209-54-53131

COVER

12

01010-31220

BOLT

13

01643-31232

WASHER

14

209-54-12280

HANDLE

15

01010-51230

BOLT

16

01643-31232

WASHER

17

208-54-12210

BAR, TORSION

18

209-54-53151

STAY

19

01643-31645

WASHER

20

04050-04028

PIN

21

205-54-76530

LATCH, HOOD

22

01010-50825

BOLT

23

01643-30823

WASHER

24

205-54-67660

SUPPORT

25

01010-50825

BOLT

26

01643-30823

WASHER

27

205-54-76260

LATCH, LOCKING HOOD

28

205-54-76280

ROTOR ASSEMBLY, LOCK

29

01010-50825

BOLT

30

01643-30823

WASHER

31

205-54-67660

SUPPORT

32

01010-50825

BOLT

33

01643-30823

WASHER

34

01010-51230

BOLT

35

01643-31232

WASHER

36

01010-51230

BOLT

37

01643-31232

WASHER
