Запчасти Komatsu PC650-5 & PC650LC-5 ПРАВ. УПРАВЛ-Е СТОЙКА P.P.C. ТРУБЫ С -STAGE SELECTOR MODE OLSS И БЕЗ РАДИО КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

209-62-57641

ELBOW

2

07002-03034

O-RING

3

209-62-57640

ELBOW

4

07002-02034

O-RING

5

07230-20315

UNION

6

07002-02034

O-RING

7

07230-20315

UNION

8

07102-20312

HOSE, (P)

9

07102-20313

HOSE, (T)

10

07102-20310

HOSE, (A)

11

07102-20310

HOSE, (B)

12

07102-20310

HOSE, (C)

13

07102-20310

HOSE, (D)

14

203-43-51131

BOOT, RIGHT HAND CONTROL LEVER

15

209-43-63180

LEVER, RIGHT HAND CONTROL

16

01010-50825

BOLT

17

01643-30823

WASHER

18

01583-11408

NUT

19

209-43-61171

LEVER

20

209-43-61330

LEVER, FUEL CONTROL

21

201-43-62120

KNOB

22

01225-70520

SCREW

23

01010-50825

BOLT

24

01643-30823

WASHER

25

209-43-61340

SCREW

26

205-06-78210

WASHER

27

20Y-06-15160

SWITCH, SWING LOCK

28

203-06-41680

CAP

29

205-06-64540

LAMP, SWING LOCK

30

209-06-62210

SWITCH ASSEMBLY, KEY START

31

203-06-51120

LIGHTER, CIGARET

32

209-06-51760

SWITCH ASSEMBLY, ETHER INJECTOR
