Запчасти Komatsu PC650-5 & PC650LC-5 КОНДИЦ. ВОЗДУХА РЫЧАГ УПРАВЛ-Я ASSEMBLY КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$0

209-979-6280

CONTROL LEVER ASSEMBLY

1

ND146440-2241

PANEL

2

ND054000-6220

SWITCH ASSEMBLY, BLOWER

3

ND116593-0100

COVER, BEARING

4

ND949120-0170

BALL, STEEL

5

ND116633-1010

SPRING

6

ND116593-0160

COVER, BEARING

7

ND949120-0090

BALL, STEEL

8

ND116633-1550

SPRING

9

ND017730-7080

LEVER SUB ASSEMBLY, DUCT CONTROL

10

ND017730-7091

LEVER SUB ASSEMBLY, TEMPERATURE CONTROL

11

ND017730-7100

LEVER SUB ASSEMBLY, FRESH AIR CONTROL

12

ND949083-0950

PIN

13

ND949017-0340

WASHER, WAVE

14

ND949010-0590

WASHER

15

ND90577-05000

E-RING

16

ND949083-0560

PIN

17

ND116563-1120

CLAMP, WIRE CABLE

18

ND949006-3250

SCREW

19

ND91370-04101

SCREW WITH WASHER

20

ND948040-1590

BOLT

21

ND017770-0280

KNOB SUB ASSEMBLY, CONTROL
