Запчасти Komatsu PC650-5 & PC650LC-5 СИСТЕМА СМАЗКИ МАСЛООХЛАДИТЕЛЬ ДВИГАТЕЛЬ

1

1239 239 H1

TUBE, WATER BYPASS

2

1240 052 H1

O-RING

3

1239 201 H1

CONNECTION, WATER BYPASS

4

140 483 H1

BOLT, W/WASHER - 3/8-16 X 1 1/4

5

1239 332 H1

BOLT, W/WASHER - 5/16-18 X 3/4

6

1295 458 H1

HOSE, PLAIN

7

1241 351 H1

CLAMP, HOSE

8

1295 718 H1

GASKET, CONNECTION

9

1239 913 H1

CLIP

|$9

1241 365 H91

COOLER, ENGINE OIL

10

1237 989 H1

BOLT - 3/8-24 X 3 3/4

11

120 382

WASHER, LOCK

12

1238 127 H1

DRAINCOCK

13

1238 237 H1

WASHER, PLAIN

14

1238 775 H1

GASKET, OIL COOLER

15

1239 273 H1

BOLT, W/WASHER - 3/8-16 X 3 1/2

16

1241 342 H1

BOLT, W/WASHER - 3/8-16 X 1 5/8

17

1239 248 H2

GASKET, TORQUE CONVERTER OIL COOLER

18

1238 328 H1

O-RING

19

1241 313 H1

PLUG, THREADED

20

1241 364 H1

COVER, LUBE OIL COOLER

21

1239 931 H1

CORE, LUBE OIL COOLER

22

1239 934 H91

PLUG, THREADED

23

1250 824 H1

HOUSING, OIL COOLER

24

120 382

WASHER, LOCK

25

1238 237 H1

WASHER, PLAIN

26

1241 309 H1

BOLT, TWELVE POINT - 3/8-16 X 1 3/4

27

1241 336 H1

BOLT, W/WASHER - 3/8-16 X 1 5/8

28

1239 759 H1

BOLT, W/WASHER - 3/8-16 X 1 1/4

30

1239 776 H1

BOLT, W/WASHER - 3/8-16 X 4

31

1239 878 H2

GASKET, LUBE OIL COOLER HOUSING
