Запчасти Komatsu PC650-5 & PC650LC-5 БЕЗОПАСН. СТОПОРН. КЛАПАН ГИДРАВЛИКА

|$0

209-60-62602

VALVE ASSEMBLY, SAFETY LOCK

1

209-60-52611

BODY

2

209-60-52621

SPOOL

3

209-60-52631

FLANGE

4

07016-20256

SEAL

5

07000-03025

O-RING

6

07000-03035

O-RING

7

07043-70108

PLUG

8

01010-51030

BOLT

9

01643-31032

WASHER

10

01010-31080

BOLT

11

01643-31032

WASHER

12

07000-03035

O-RING

13

209-62-57421

BLOCK

14

07750-03048

VALVE

15

07750-03056

SPRING

16

07000-03035

O-RING

17

209-60-52640

FLANGE

18

01010-51030

BOLT

19

01643-31032

WASHER

20

07040-13316

PLUG

21

07002-03334

O-RING

22

01252-31030

BOLT

23

01643-51032

WASHER

24

01010-31225

BOLT

25

01643-31232

WASHER

26

209-62-57210

TEE

27

07002-02034

O-RING

28

07236-11034

ELBOW

29

07002-03334

O-RING

30

07238-10315

CONNECTOR

31

07230-20628

UNION

32

07002-02434

O-RING

33

07371-31049

FLANGE

34

07372-21035

BOLT

35

01643-51032

WASHER

36

209-62-61310

NIPPLE ASSEMBLY

37

209-62-61330

O-RING
