Запчасти Komatsu PC650-5 & PC650LC-5 ГОЛОВКА ЦИЛИНДРОВ ДВИГАТЕЛЬ

|$0

1241 747 H92

HEAD, CYLINDER

1

NSS

HEAD, CYLINDER

2

1238 663 H1

COLLET, VALVE

3

1294 544 H2

ROTATOR, VALVE

4

1238 665 H1

RETAINER, VALVE SPRING

5

1294 543 H1

SPRING, VALVE

6

1239 681 H2

VALVE, EXHAUST

7

1294 542 H2

VALVE, INTAKE

8

1238 687 H1

GUIDE, CROSSHEAD VALVE

9

1241 642 H1

GUIDE, VALVE STEM

10

1238 664 H1

INSERT, VALVE

11

1240 019 H1

PIN, GROOVE

12

1294 545 H1

INSERT, VALVE

13

1238 721 H1

PLUG, EXPANSION

14

1238 755 H1

PLUG, EXPANSION

15

1240 004 H1

PLUG, PIPE

16

1238 125 H1

PLUG, PIPE

17

1238 634 H1

PLUG, EXPANSION

18

1239 173 H1

PLATE, SWIRL

19

1239 635 H1

BOLT, TWELVE POINT 3/4-16 X 8

20

1238 656 H1

WASHER, PLAIN

21

1241 635 H91

GASKET, CYLINDER HEAD

22

1238 741 H1

SEAL, GROMMET

23

1238 812 H1

SEAL, GROMMET

24

1238 742 H1

SEAL, GROMMET

25

1238 743 H1

SEAL, GROMMET

26

1238 627 H1

NUT, HEAVY HEX - 3/8-24

27

1250 683 H91

CROSSHEAD, VALVE

28

1239 637 H1

SCREW, CROSSHEAD VALVE ADJUSTING

|$34

1241 598 H2

GASKET, CYLINDER HEAD - 0.020

22

1238 741 H1

SEAL, GROMMET

23

1238 812 H1

SEAL, GROMMET

24

1238 742 H1

SEAL, GROMMET

25

1238 743 H1

SEAL, GROMMET
