Запчасти Komatsu PC650-5 & PC650LC-5 ПОВОРОТН. НАСОС CRADLE ASSEMBLY ГИДРАВЛИКА

|$1

708-27-00212

CRADLE ASSEMBLY

|$2

708-27-00380

CRADLE SUB ASSEMBLY

1

NSS

CRADLE

2

NSS

PLUG

3

708-27-13412

CAM, ROCKER

4

708-27-12350

STOPPER

5

04020-00820

PIN, DOWEL

6

706-75-42270

SCREW

7

708-27-13342

RETAINER, SHOE

8

708-27-05051

SPACER KIT

|$11

NSS

SPACER, 13.540MM

|$12

NSS

SPACER, 13.560MM

|$13

NSS

SPACER, 13.575MM

9

708-27-13420

RETAINER

10

708-27-13480

SCREW

11

01643-30823

WASHER

12

708-27-12330

PLATE

13

04020-00820

PIN, DOWEL

14

708-27-12340

SCREW

15

01643-30823

WASHER

16

708-27-14121

SLIDER

17

708-27-12130

O-RING

18

07000-12015

O-RING

19

708-25-12330

JOINT

20

706-87-50360

BOLT

21

708-17-22710

SHAFT

22

708-27-12730

BEARING

23

708-17-05010

WASHER KIT

|$29

NSS

WASHER, 3.0MM

|$30

NSS

WASHER, 3.1MM

|$31

NSS

WASHER, 3.2MM

24

708-17-12780

RING

25

708-17-12790

HOUSING

26

708-27-22810

SEAL, OIL

27

07000-02105

O-RING

28

708-27-05010

SHIM KIT

|$37

NSS

SHIM, 0.05MM

|$38

NSS

SHIM, 0.10MM

|$39

NSS

SHIM, 0.15MM

29

01010-50820

BOLT

30

01643-30823

WASHER

|$42

708-27-00360

BLOCK ASSEMBLY, CYLINDER

31

708-27-13112

BLOCK

32

708-27-23230

VALVE, PLATE

33

708-27-13314

PISTON SUB ASSEMBLY

34

708-27-13120

WASHER

35

708-27-13140

SPRING

36

708-27-13130

RETAINER

37

708-27-13150

RING
