Запчасти Komatsu PC650-5 & PC650LC-5 ГИДР. НАСОС. NO. END КРЫШКАS ГИДРАВЛИКА

|$1

708-25-00660

END CAP ASSEMBLY, FRONT

1

NSS

CAP

2

NSS

PLUG

3

708-25-52590

END CAP, REAR

4

708-2E-12260

BEARING

5

06000-51106

BEARING

6

708-25-05140

WASHER KIT

|$8

NSS

WASHER, 2.25MM

|$9

NSS

WASHER, 2.55MM

|$10

NSS

WASHER, 2.85MM

|$11

NSS

WASHER, 3.15MM

|$12

NSS

WASHER, 3.45MM

|$13

NSS

WASHER, 3.75MM

7

708-25-52830

RING

8

708-25-52840

RETAINER

9

708-25-12950

PLATE

10

708-25-05021

SHIM KIT

|$18

NSS

SHIM, 0.1MM

|$19

NSS

SHIM, 0.15MM

|$20

NSS

SHIM, 0.2MM

|$21

NSS

SHIM, 0.5MM

11

706-74-40320

BOLT

12

01643-31032

WASHER

13

708-25-52550

COUPLING

14

708-25-12542

IMPELLER

15

706-73-42270

SCREW

16

07000-02135

O-RING

17

07000-03032

O-RING

18

07000-12015

O-RING

19

07000-11009

O-RING

20

6130-21-1910

PIN

21

720-68-19610

PIN, DOWEL

22

708-25-12530

BOLT

23

07000-05165

O-RING

24

07000-03032

O-RING

25

07000-11009

O-RING

26

720-68-19610

PIN, DOWEL

27

01141-81620

STUD

28

01140-81645

STUD

29

01582-01613

NUT

30

01643-31645

WASHER

31

708-25-13630

RING
