Запчасти Komatsu PC650-5 & PC650LC-5 ГИДР. НАСОС. NO. ПЕРЕДН. CRADLE ГИДРАВЛИКА

|$1

708-25-00331

CRADLE ASSEMBLY, FRONT

|$2

708-25-00520

CRADLE SUB ASSEMBLY, FRONT

1

NSS

CRADLE, FRONT

2

NSS

PLUG

3

708-25-13411

ROCKER, CAM

4

708-25-13422

RETAINER , SHOE

5

708-25-05061

SPACER KIT

|$8

NSS

SPACER, 11.540MM

|$9

NSS

SPACER, 11.560MM

|$10

NSS

SPACER, 11.575MM

6

708-25-13441

RETAINER

7

708-25-13470

SCREW

8

01643-30623

WASHER

9

708-25-12360

PLATE

10

04020-00820

PIN, DOWEL

11

01010-50816

BOLT

12

708-25-14121

SLIDER

13

708-25-12340

O-RING

14

07000-12015

O-RING

15

708-25-12330

JOINT

16

708-25-12350

BOLT

17

708-25-52710

SHAFT, FRONT

18

708-25-12731

BEARING

19

708-25-05010

KIT, WASHER

|$25

NSS

WASHER, 2.0MM

|$26

NSS

WASHER, 2.1MM

|$27

NSS

WASHER, 2.2MM

20

708-25-12790

RING, SNAP

21

708-25-12812

HOUSING

22

708-25-52860

SEAL

23

07000-02080

O-RING

24

708-25-05130

SHIM KIT

|$33

NSS

SHIM, 0.1MM

|$34

NSS

SHIM, 0.2MM

25

01010-50820

BOLT

26

01643-30823

WASHER

|$37

708-25-00401

BLOCK ASSEMBLY, FRONT

27

708-25-13151

BLOCK, CYLINDER

28

708-25-13611

PLATE

29

708-25-13312

PISTON SUB ASSEMBLY

30

708-25-13130

SPRING

31

708-25-13120

WASHER

32

708-25-13140

RING, SNAP
