Запчасти Komatsu PC650-5 & PC650LC-5 ГИДР. НАСОС. NO. ПЕРЕДН. CO & NC КЛАПАН ASSEMBLY ГИДРАВЛИКА

|$0

708-25-09511

VALVE ASSEMBLY, FRONT CO & NC

|$1

708-23-00441

BODY ASSEMBLY

1

NSS

BODY

2

NSS

PLUG

3

708-25-17141

SPOOL

4

708-25-17131

COVER

5

708-25-17180

SEAT

6

708-25-17690

SPRING

7

708-25-17460

PLUG

8

708-25-17430

SCREW

9

07000-02010

O-RING

10

07000-12021

O-RING

11

07001-02021

RING

12

708-25-15320

BOLT

13

01602-20619

WASHER, SPRING

14

01580-10806

NUT

15

708-25-17150

SLEEVE

16

708-25-17160

PISTON

17

708-25-17170

COVER

18

07000-02014

O-RING

19

708-25-15320

BOLT

20

01602-20619

WASHER

21

708-25-17141

SPOOL

22

708-25-17451

SLEEVE

23

07000-12012

O-RING

24

07001-02012

RING, BACK-UP

25

708-25-17220

PISTON

26

07000-02012

O-RING

27

708-25-15320

BOLT

28

01602-20619

WASHER

29

708-25-17370

SEAT

30

708-25-17250

SPRING

31

708-25-17260

SEAT

32

708-23-17290

COVER

33

07000-03028

O-RING

34

706-75-40310

BOLT

35

01602-20619

WASHER, SPRING

36

708-23-17270

PISTON

37

708-25-17380

PLUG

38

07000-02021

O-RING

39

708-25-15340

SCREW

40

708-23-17240

COVER

41

708-25-15320

BOLT

42

01602-20619

WASHER, SPRING

43

01580-10806

NUT
