Запчасти Komatsu PC650-5 & PC650LC-5 ГИДР. НАСОС. NO. ПЕРЕДН. СЕРВОКЛАПАН ASSEMBLY ГИДРАВЛИКА

|$0

708-25-09311

VALVE ASSEMBLY, FRONT SERVO

|$1

708-23-00421

BODY ASSEMBLY

1

NSS

BODY

2

NSS

PLUG

3

708-25-15120

PISTON

4

708-25-15270

ARM

5

708-25-15360

PIN

6

708-25-15370

WASHER

7

708-25-15380

E-RING

8

708-25-15130

SEAT

9

708-25-55130

SPRING

10

708-23-15120

SEAT

11

708-25-55120

SPRING

12

708-23-15160

PLUG

13

708-25-15340

SCREW

14

07000-02018

O-RING

15

708-25-15150

COVER

16

708-25-15320

BOLT

17

01602-20619

WASHER

18

01580-10806

NUT

19

708-25-55670

PLUG

20

07239-12009

NUT

21

07002-02034

O-RING

22

708-25-15180

SLEEVE

23

708-25-15280

SPOOL

24

708-25-15260

PLUG

25

07002-00823

O-RING

26

708-25-15310

SPRING

27

708-25-15330

SPACER

28

07000-02012

O-RING

29

708-25-15430

PLUG

30

708-25-15340

SCREW

31

07000-02012

O-RING

32

708-25-15250

COVER

33

708-25-15320

BOLT

34

01602-20619

WASHER, SPRING

35

708-25-15340

SCREW

36

01580-10806

NUT
