Запчасти Komatsu PC650-5 & PC650LC-5 ГИДР. НАСОС. NO. END КРЫШКАS ГИДРАВЛИКА

|$1

708-25-00420

END CAP ASSEMBLY, FRONT

1

NSS

CAP

2

NSS

PLUG

|$4

708-25-00440

END CAP ASSEMBLY, REAR

3

NSS

CAP

4

NSS

PLUG

5

708-2E-12660

BEARING

6

06000-51106

BEARING

7

708-25-05140

WASHER KIT

|$10

NSS

WASHER, 2.25MM

|$11

NSS

WASHER, 2.55MM

|$12

NSS

WASHER, 2.85MM

|$13

NSS

WASHER, 3.15MM

|$14

NSS

WASHER, 3.45MM

|$15

NSS

WASHER, 3.75MM

8

708-25-52830

RING

9

708-25-52840

RETAINER

10

708-25-12950

PLATE

11

708-25-05021

SHIM KIT

|$20

NSS

SHIM, 0.1MM

|$21

NSS

SHIM, 0.15MM

|$22

NSS

SHIM, 0.2MM

|$23

NSS

SHIM, 0.5MM

12

706-74-40320

BOLT

13

01643-31032

WASHER

14

708-25-52550

COUPLING

15

708-25-12542

IMPELLER

16

706-73-42270

SCREW

17

07000-02135

O-RING

18

07000-03032

O-RING

19

6130-21-1910

PIN

20

720-68-19610

PIN, DOWEL

21

708-25-12530

BOLT

22

07000-05165

O-RING

23

07000-03032

O-RING

24

720-68-19610

PIN, DOWEL

25

01141-81620

STUD

26

01140-81645

STUD

27

01582-01613

NUT

28

01643-31645

WASHER

29

708-25-12530

BOLT

30

07000-11009

O-RING

31

07000-12015

O-RING

32

07000-12012

O-RING

33

708-25-13630

RING
