Запчасти Komatsu PC650-5 & PC650LC-5 ПОВОРОТН. УПРАВЛЯЮЩ. КЛАПАН РАЗГРУЗ. КЛАПАНS ГИДРАВЛИКА

|$0

700-91-36000

VALVE ASSEMBLY, SWING CONTROL (SEE PG H-0066)

|$1

700-92-55000

VALVE ASSEMBLY, MAIN RELIEF

1

NSS

SLEEVE

2

NSS

VALVE

3

700-90-51320

SPRING

4

700-90-51120

PLUG

5

700-90-51150

PLUG

6

07000-22016

O-RING

7

07001-02016

RING, BACKUP

8

700-80-61190

POPPET

9

700-80-51240

SPACER

10

700-90-51160

SPRING

11

700-90-51250

RETAINER

12

700-90-51270

HOLDER

13

700-90-51190

NUT

14

07002-03034

O-RING

15

700-90-51281

SCREW

16

01580-10806

NUT

17

700-90-51311

NUT

18

700-90-51290

WASHER

19

700-93-11320

O-RING

20

700-93-11330

RING, BACKUP

21

07002-03634

O-RING

|$23

700-90-62000

VALVE ASSEMBLY, SUCTION

22

NSS

SLEEVE

23

NSS

VALVE

24

700-90-61170

SPRING

25

700-90-62130

PLUG

26

07002-13034

O-RING

27

700-93-11320

O-RING

28

700-93-11330

RING, BACKUP

29

07002-03634

O-RING

|$32

700-90-99000

VALVE ASSEMBLY, SENSOR & RELIEF

30

700-93-12651

BODY

31

700-93-12660

ORIFICE

32

709-90-91110

SENSOR

33

07000-02014

O-RING

34

07002-02434

O-RING

|$38

709-10-55200

VALVE ASSEMBLY, RELIEF

35

NSS

SLEEVE

36

NSS

VALVE

37

709-70-51320

SPRING

38

709-90-51250

RING

39

709-10-51330

SEAT

40

07000-22016

O-RING

41

709-10-51340

POPPET

42

709-10-51350

SPRING

43

709-10-51360

HOLDER

44

700-90-51190

NUT

45

07002-03034

O-RING

46

709-10-51370

SCREW

47

01582-11411

NUT

48

07000-02011

O-RING

49

700-93-11320

O-RING

50

700-93-11330

RING, BACKUP

51

07002-03634

O-RING
