Запчасти Komatsu PC650-5 & PC650LC-5 ГИДР. БАК. ДАТЧИК И ЗАЩИТА ОТ ВАНДАЛИЗМА ГИДРАВЛИКА

1

207-60-11350

TUBE

2

07280-01110

CLAMP

3

7861-92-4520

SENSOR, HYDRAULIC OIL LEVEL

4

07002-23634

O-RING

5

209-06-61341

SENSOR, HYDRAULIC OIL TEMPERATURE (HIGH)

6

7861-92-1940

SWITCH, HYDRAULIC OIL FILTER

7

07000-02014

O-RING

8

01252-40640

BOLT

9

7861-92-3400

SENSOR, HYDRAULIC OIL TEMPERATURE (LOW)

10

209-06-61232

WIRING HARNESS

11

08053-01512

CLIP

12

08036-01014

CLIP

13

08053-01512

CLIP

14

01010-51225

BOLT

15

01643-31232

WASHER

16

600-815-3210

CASE

17

07000-02055

O-RING

18

01010-51075

BOLT

19

01643-31032

WASHER

20

01010-52045

BOLT

21

01643-32060

WASHER

22

209-60-51140

COVER

23

09445-02013

HINGE

24

209-60-51150

BRACKET

25

205-60-71220

LOCK ASSEMBLY

26

205-54-76280

ROTOR ASSEMBLY

27

01010-51240

BOLT

28

01643-31232

WASHER
