Запчасти Komatsu PC650-5 & PC650LC-5 INTAKE КОЛЛЕКТОР ДВИГАТЕЛЬ

1

1238 804 H1

TUBE, WATER TRANSFER

2

1239 030 H1

TUBE, WATER TRANSFER

3

1238 767 H1

SEAL, GROMMET

4

1239 004 H2

COVER, AFTERCOOLER

5

1239 005 H1

RETAINER, SEAL

6

1239 006 H1

GASKET, AFTERCOOLER COVER

7

1239 007 H1

GASKET, CONNECTION

8

1239 227 H2

HOUSING, AFTERCOOLER

9

1294 607 H1

BOLT, W/WASHER - 3/8-16 X 4 15/16

10

1239 321 H1

BOLT, W/WASHER - 3/8-16 X 1

11

1241 335 H1

GASKET, AFTERCOOLER COVER

12

1241 342 H1

BOLT, W/WASHER - 3/8-16 X 1 7/8

13

1239 885 H1

PLATE, COVER

14

1296 827 H1

BOLT - 3/8-16 X 2 3/4

16

1239 267 H1

BOLT, W/WASHER - 3/8-16 X 1 1/2

17

1246 345 H1

CLAMP, HOSE

18

1239 225 H1

CLIP

19

1246 352 H1

HOSE, PLAIN

20

1238 316 H1

ELBOW, MALE ADAPTER

21

1239 212 H1

BOLT, W/WASHER - 3/8-16 X 1

22

1295 958 H1

FLANGE, WELD

23

1239 226 H1

GASKET, FLANGE

24

1239 371 H1

HOSE, PLAIN

25

1239 849 H1

TEE, STREET PIPE

26

1239 915 H91

TUBE, VENT

27

1239 918 H1

CONNECTION, WATER TRANSFER

28

1239 565 H1

SEAL, O RING
