Запчасти Komatsu PC650-3 & PC650LC-3 ТОПЛИВН. НАСОС КОЖУХ ТОПЛИВН. СИСТЕМА

|$0

1294 741 H91

HOUSING, FUEL PUMP

1

NSS

BODY, FUEL PUMP

2

1238 887 H1

BALL, PLUG AFC

3

1241 477 H1

HOUSING, SPRING PACK

4

NSS

BARREL, GOVERNOR

5

1238 137 H1

BUSHING, TACHOMETER DRIVE

6

1238 209 H1

DOWEL, RING

|$7

1241 340 H91

PLUNGER, GOVERNOR

7

1240 057 H1

DRIVER, GOVERNOR PLUNGER

8

1250 107 H1

SPACER, BEARING

9

1241 339 H1

PLUNGER, GOVERNOR

10

1239 514 H1

PLUG, PIPE

11

1238 141 H1

O-RING

12

1238 392 H1

RING, RETAINING

13

1238 883 H1

O-RING

14

1239 114 H1

SCREW, FUEL PUMP ADJUSTING - 1/4-28 X 27/32

|$16

1294 268 H91

SHAFT ASSEMBLY, THROTTLE

15

1239 118 H1

STOP, THROTTLE LEVER

16

1239 119 H1

SCREW, SET HEX FLAT SOCKET - 1/4-28 X 3/8

17

1239 829 H1

SHAFT, THROTTLE

18

1238 884 H1

PLUG, BALL

19

1238 978 H1

COVER, FUEL CONTROL

20

1239 551 H1

BEARING, THRUST

21

1246 109 H1

SCREW, DRIVE

22

1250 262 H1

NUT, HEX - 1/4-28

23

1240 058 H1

SPRING, COMPRESSION

24

1238 373 H1

CAP, FUEL PUMP FILTER

25

1238 367 H1

O-RING

26

1238 338 H1

SCREEN, FILTER

27

1239 515 H1

PLUG, PIPE

28

1238 531 H1

PLUG, PIPE

29

1239 455 H1

CONNECTOR, FEMALE

30

1239 824 H1

BOLT, SOCKET SET - 1/4-28 X 1 1/2

31

1238 184 H1

NUT, FUEL PUMP ADJUSTING

32

1238 312 H1

PLUNGER, GOVERNOR WEIGHT ASSIST

33

1240 060 H1

GASKET, SPRING PACK FLANGE

34

1238 053 H1

RING, RETAINING

35

1240 061 H1

RETAINER, SPRING

36

1241 685 H91

COVER, SPRING PACK

37

1239 369 H1

BOLT, W/WASHER - 1/4-20 X 1 1/8

38

1240 064 H1

SHIM, GOVERNOR

|$38

1240 065 H1

SHIM, GOVERNOR

|$39

1240 066 H1

SHIM, GOVERNOR

39

1240 063 H1

SCREW, KNURLED - 3/16-28 X 1 1/4

40

1239 705 H1

GUIDE, IDLE SPRING

41

1240 062 H1

WASHER, PLAIN

42

1238 844 H1

PIN, GOVERNOR

43

1238 144 H1

SHIM - .005 IN

|$45

1238 145 H1

SHIM - .010 IN

|$46

1238 146 H1

SHIM - .020 IN

44

1238 313 H1

SHIM

45

1238 308 H1

SPRING, COMPRESSION

46

1239 509 H91

CARRIER ASSEMBLY, GOVERNOR

47

NSS

SPRING, GOVERNOR - MAX

48

NSS

PLUNGER, IDLE SPRING

49

1239 628 H1

SPRING, COMPRESSION

50

1239 406 H1

SPRING, COMPRESSION

51

1240 007 H1

O-RING

52

1238 977 H1

PLUG, BARREL

53

90 897

O-RING

54

1238 323 H1

O-RING

55

1294 735 H1

PLUG, 0-RING

56

1239 096 H1

PLATE COVER

57

1239 557 H1

GASKET, COVER

58

NSS

BOLT, FILH SPRINGTITE (1/4 - 20x1 INCH)

59

NSS

WASHER

N/I

1239 067 H1

SEAL, WIRE

N/I

1239 399 H1

BOLT, FILLISTER HEAD - 1/4-20x1
